Application Based CODESYS Virtualization License

CODESYS Visualization M

The application-based license CODESYS Visualization M enables a CODESYS visualization with up to 2048 data points. This can be displayed as a WebVisu, as a TargetVisu or both.

Function

Alarm management, trace and trend display, user management, recipe management, visualization styles, multi-axiality, integration of HTML5 controls in the CODESYS WebVisu

HAVE A QUESTION?

SKU/Order No.: SA-CDS-VISU-M-00

Additional Information

CODESYS Visualization is an add-on product for the CODESYS Control SL product to equip it with a graphical user interface (visualization/HMI). The visualization can be used as WebVisu or TargetVisu, depending on the expansion stage of the device.

The CODESYS WebVisu opens up the possibility of displaying graphical user interfaces on display devices with HTML5-capable web browsers that are connected to a control device via a data network.

The CODESYS TargetVisu can display graphical user interfaces directly on the control panel of the control device, if the device in question has a display.

Performance class Virtualization: Visu M (number of tags: 2048)

Tags are IEC variables used within the visualization. Complex elements like table or trend, use further criteria to calculate the number of necessary tags.

Benefits of CODESYS Visualization:

  • Integrated in the CODESYS Development System, for the development of the visualization/HMI

  • Development independently or together with the PLC application in a project

  • Scalable projects by enabling any number of usable tags

  • Simplified new creation of the application through guided project configuration

  • Access to data in the control network via data sources

  • Extensible library of elements from self-created visualizations with parameter interface

  • Loading of the visualization directly from the development environment to the controller

    • Alarm management

    • Trace and trend display

    • User management

    • Recipe management

    • Visualization styles

    • Multi-axiality

    • Integration of HTML5 Controls in the CODESYS WebVisu



FOR MORE DETAILS ON THE LICENSE, VISIT: CODESYS Virtualization M
