Series CP socket 2 changeover contacts with Screw connection
Socket CP 2C Screw
Relay socket with 2 changeover contacts with Screw connection technology
Function2 changeover contacts, control voltage: 300 V, contact load: 10 A, Screw wiring, 15.7 mm wide, CE and RoHS compliant
Features- Manufactured by SALZ Automation
- Slim Design
- 10 A switching capability
- DIN rail mounting
- High insulation capability
- Wide Operating Temperature
SKU/Order No.: SA-CP2C-SOCK-E
Additional Information
This compact socket from the CP relay series has two changeover contacts and is therefore versatile for controlling multiple circuits. The socket operates with a control voltage of 300 V AC and is designed for a contact load of 10 A. It is made of a lightweight material (41.5 g) and, with a width of just 15.7 mm, is suitable for various mounting applications. The screw connection terminals, retaining brackets and markers enable quick wiring and easy installation. In addition, the socket complies with CE and RoHS standards, ensuring safety and environmental compatibility in design and manufacture.
Manufactured by SALZ Automation
Slim Design
Takes lesser space as the socket is slim desingned.
10 A switching capability
Contact rating 10 A
DIN rail mounting
The socket can be mounted on a DIN rail.
High insulation capability
High insulation capability of 5 kV surge voltage between input and output
Wide Operating Temperature
Relay's housing featuring wide operating temperature range designed for harsh environments.
